Fanvil H7
Fanvil H7 è un telefono IP per postazioni direzionali e reception, dotato di bluetooth, wifi, 100 tasti programmabili, supporta webcam USB
Il videotelefono IP Fanvil H7, è un terminale direzionale per clienti che cercano un telefono VoIP non ingombrante ma con tutte le funzioni necessarie in una moderna postazione di lavoro ad alte prestazioni.
Ideale in reception (centralinista), uffici direzionali...

Grazie alla webcam USB opzionale, come ad esempio la Fanvil CM60, fanvil H7 diventa un videotelefono con webcam integrata per videoconferenze, compatibile con tutti i client.
E' ricco di funzionalità ed è interoperabile praticamente con tutti i sistemi telefonici con SIP standard.
L'ampio display touch screen a colori da 7", il wifi e bluetooth integrati, la porta USB 2.0, forniscono a questo videotelefono IP tutte le connessioni per audio, cuffie e ovviamente di rete (ovviamente è dotato di 2 porte LAN Gigabit oltre al Wi-Fi dual band)
Sul display sono disponibili fino a 100 tasti funzione programmabili con etichette LCD e stato dell'interno (libero/occupato).
Fanvil H7 caratteristiche tecniche
Punti di forza del telefono IP Fanvil H7
- 20 SIP accounts
- Conferenza a 3 vie
- Display touch-screen capacitivo da 7" a colori
- Audio su speaker, microtelefono e cuffia in HD
- Built-in Bluetooth 4.2
- WiFi 2.4G/5G
- Fino a 100 tasti DSS programmabili sul display
- Video Codec H.264
- Dual Gigabit ports
- PoE
- Supporto regolabile a 40° o 50°
- Compatibile con i più diffusi pabx: Asterisk, Broadsoft, 3CX, Metaswitch,Elastix, Avaya, Yeastar on premise, Yeastar cloud, Ezcloud...
Funzioni telefoniche
- Android 9.0 OS
- Local Phonebook (2000 entries)
- Remote Phonebook (XML/LDAP, 2000 entries)
- Call logs (In/out/missed, 1000 entries)
- Black/White List Call Filter
- Screen saver
- Voice Message Waiting Indication (VMWI)
- Programmable DSS/Soft keys
- Network Time Synchronization
- Support Recording
- Action URL / Active URI
- uaCSTA
- Frame rate selection: 5 ~30fps
- Video from remote site can be displayed in full screen
Funzionalità e caratteristiche audio
- HD Voice Microphone/Speaker (Handset/Hands free, 0 ~ 7KHz
- Frequency Response)
- HAC handset
- Wideband ADC/DAC 16KHz Sampling
- Narrowband C odec : G.711a/u, G. iLBC
- Wideband C odec : G.722 , Opus
- Full duplex Acoustic Echo Canceller (AEC)
- Noise Reduction (NR)
- Packet Loss Concealment (PLC)
- Dynamic Adaptive Jitter Buffer
- DTMF: In band, Out of Band DTMF Relay(RFC2833) / SIP INFO
Rete
- Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PCbypass
- IP Mode:IPv4
- IP Conf iguration: Static / DHCP
- Network Access Control: 802.1x
- VPN: OpenVPN Requires third party app support)
- VLAN
- LLDP
- CDP
- QoS
Protocolli
- SIP2.0 over UDP/TCP/TLS
- RTP/RTCP/SRTP
- STUN
- DHCP
- CDP
- LLDP
- PPPoE
- 802.1x OpenVPN (Requires third-party app support)
- SNTP
- FTP/TFTP
- HTTP/HTTPS
- TR-069
Funzioni di chiamata
- Call out / Answer / Reject
- Mute / Unmute (Microphone)
- Call Hold / Resume
- Call Waiting
- Intercom
- Caller ID Display
- Speed Dial
- Anonymous Call (Hide Caller ID)
- Call Forwarding (Always/Busy/No Answer)
- Call Transfer (Attended/Unattended)
- Call Parking/Pick-up (Depending on server)
- Redial
- Do-Not-Disturb
- Auto-Answering
- Voice Message (On server)
- 3-way Conference
- Hot Line
- Hot desking
Funzionalità e caratteristiche video
- Video decoding: H.264
- Video call resolution: CIF/VGA/4CIF/720P
- Image format: JPEG/PNG/BMP
- Video format: MP4
- Bandwidth selection: 64kbps~4Mbps
- Videocamera CM60 OPZIONALE
Deployment & Management
- Auto Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP
- PNP/TR 069
- Web Management Portal
- Supports the third party communication APP
- Supports Web, Telnet
- Supports encrypted configuration files download with AES
- Supports Web upgrade
- Supports factory reset data
Caratteristiche fisiche
- Color: Black
- LCD x1: 7- inch (1024x600) color touch screen Touch keys x5: Volume -/Volume +/Home/Return/Hands-free HD Handset (RJ9) x1
- Standard RJ9 Handset Wire x1
- 1.5M CAT5 Ethernet Cable x1
- Back Rack x1
- RJ9 Port x2: Handset x1, Headset x1
- RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
- USB2.0 Port x1: Standard A, Connect with Flash Driver Safety keyhole x1
- Power: 5V/2A or PoE
- Power Consumption (PoE): 2.39W ~ 8.77W
- Power Consumption (Adapter): 1.64W ~ 6.9W
- Working Temperature: 0~45℃
- Working Humidity: 10~95%
- Installation: Desktop stand
- Wall-mounted (need an additional wall hanging parts)
- Device Dimensions Desktop stand (angles 1: 40 degree): 181 x 175.75 x 184.4 mm
- Desktop stand (angles 2: 50 degree): 181 x 175.85 x 185.1 mm
- Wall-mounted: 181 x 115.43 x 208.75 mm
