* In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.The parameters and datasheets below can only be applied to 1500-S2 series.
Technical Specification
Camera
Image Sensor 1/2.7 inch CMOS
Max. Resolution 2880 (H) × 1620 (V)
Pixel 5MP
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25 s–1/100,000 s
NTSC: 1/30 s–1/100,000 s
S/N Ratio > 65 dB
Min. Illumination 0.005 Lux/F1.6, 30IRE, 0 Lux IR on
Illumination Distance 60 m (196.9 ft)
Illuminator On/Off Control Auto; manual
Illuminator Number 4
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type Motorized vari-focal
Auto Focus N/A
Mount Type φ14
Focal Length 2.7 mm–12 mm
Max. Aperture F1.6
Field of View
Diagonal: 39°–130°
Horizontal: 34°–107°
Vertical: 19°–55°
Iris Type Fixed iris
Close Focus Distance 0.5 m (1.64 ft)
DORI
Distance
Video
Frame Rate
CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps
NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
CVBS:
PAL: 960H;
NTSC: 960H
Resolution 5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 ×1080); 960H (960 × 576/960 × 480)
Day/Night Auto switch by ICR BLC BLC/HLC/DWDR WDR DWDR
White Balance Auto; manual
Gain Control Auto; manual
Noise Reduction 2D NR
Smart IR Yes
Mirror Off/On
Privacy Masking Off/On (8 areas, rectangle)
Certifications
Certifications
CE (EN55032:2015, EN 61000-3-2:2014, EN
61000-3-3:2013, EN55024:2010+A1:2015, EN
55035:2017, EN50130-4:2011+A1:2014, EN 62368-
1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Port
Audio Output One channel built-in mic
Video Output Video output choices of CVI/TVI/AHD/CVBS by oneBNC port
Power
Power Supply PoC (only CVI)/12V±30% DC
Power Consumption Max 9.8W (12V DC, IR on); PoC (AT)
Environment
Operating Temperature –30°C to +60°C (–22°F to +140°F); < 95% (non-condensation)
Storage Temperature –30°C to +60°C (–22°F to +140°F); < 95% (non-condensation)
Protection Grade IP67
Structure
Casing Metal throughout the whole casing
Camera Dimensions 209.9 mm × 90.4 mm × 90.4 mm (8.26" × 3.56" × 3.56")
Net Weight 0.55 kg (1.21 lb)
