Dnake 290M-S8 monitor interno a 2 fili display 7" PoE

Dnake 290M-S8 monitor interno a 2 fili display 7" PoE

The DNAKE 290M-S8 is designed for upgrading existing 2-wire intercom system to IP system in apartment buildings. It can be connected to some old 2-wire buildings with no cable replacement. It provides multiple functions, including audio and video intercom, emergency call, security alarm and lift control, etc.

KEY FEATURES:

• Easy configuration
• 7-inch capacitive touch screen
• Powered and communicated by 2-wire
• Support SIP 2.0 protocol, easy integration with other SIP devices
• Easy integration with elevator control system
• Support monitoring 8 IP cameras

PHYSICAL:

• System: Linux
• RAM: 64 MB
• ROM: 128 MB
• Front Panel: Plastic
• Power Supply: Two wire supply
• Standby Power: 1.5 W
• Rated Power: 9 W
• Ethernet Port: 2-wire port
• RS485: 1
• Power Output: 1 (12V/100mA)
• Doorbell Input: 8 (use any alarm input port)
• Alarm Input: 8
• Installation: Surface Mounting
• Dimension: 221.4 x 151.4 x 16.5 mm
• Working Temperature: -10℃ to +55℃
• Storage Temperature: -40℃ to +70℃
• Working Humidity: 10% to 90% (non-condensing) Datasheet Display Audio Video Networking Package Features

DISPLAY:

• Display: 7-inch TFT LCD
• Screen: Capacitive touch screen
• Resolution: 800 x 480

AUDIO:

• Audio Codec: G.711
• Echo Cancellation
• DTMF: RFC2833
• Microphone: Built-in microphone
• Speaker: Built-in speaker

VIDEO:

• Video Codec: H.264

NETWORKING:

• Protocol: SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP

Package Content:

• DNAKE 290M-S8 (Power adapter not included)
• Bracket - Screwing Kit
• Quick Start Guide
